Functional characteristics:



This product can effectively shield the microwave signals between the launching pad (base station) and the mobile phone, making it necessary to shield CDMA800 (China Unicom), GSM900 (China Mobile, China Unicom), DCS (1800MHz) (China Mobile, China Unicom), PHS (Telecom PHS), 3 TD-SCDMA (mobile 3G), CDMA2000 (Telecom 3G), WC. The DMA (Unicom 3G) cell phone is connected to the outside interruption. The product is compact and easy to use. It can be applied to various environments with different areas through separate and distributed layout.





Mainly used in the examination room, the prison, the court, the hall, the library, the theater, the church, the gas station, the oil depot, the steam station, the hospital and so on, which need to be kept secret, quiet, riot and interference prevention.

Only shielding cell phone signals will not affect the normal operation of other electronic devices.

With Hitachi high performance integrated circuit, 902M VCO and patch components, the imported full automatic patch machine and reflow welder are processed and production line, the quality and performance are stable, the repair rate is not more than 2%



Launch power: 32 + 3dbm slow start time: 3 seconds to complete shielding time: 30 seconds environment temperature: -25 +60 degree C relative humidity: 35-85% power adapter: input AC100-240V 50/60Hz fuselage size: 210mm*170mm*50mm net weight: 2.0KG



Technical indicators:



The technical indexes all passed the certification of the safety and police electronic products quality inspection center of the Ministry of public security, and through the strict inspection of the environment and health related product safety of the center for disease prevention and control of China (the national authority certification body for detecting electromagnetic radiation), the measurement of the electromagnetic field intensity of each sampling point They are far below the limits specified in the electromagnetic radiation protection regulations (GB8702-88).





The latest Black 6 road A shield 4G 2G+3G+4G





TX-101E-6A4G 2G3G4G cell phone signal shield is our high-tech products imported from foreign advanced technology, imported components, according to the actual situation of domestic mobile communication. This product is independently developed, produced and sold by our company. It can effectively shield the microwave signal between the transmitter and the mobile phone. This product adopts imported original devices, professional machine patch welding technology, production line batch production, high efficient and strict management level, ensuring the quality of the products, stable performance, long-term durable! And so on



The technical indexes all passed the strict inspection of the National Radio and television product quality supervision and inspection center. The standard of environmental electromagnetic wave permissible radiation intensity classification meets the requirements of the first grade standard. It is far lower than the standard of environmental electromagnetic radiation health standard: (GB 9175-88), GB report number OTA2-20134209 detection number 2013-0420 9, "safety and police electronic products quality inspection center" - public Beijing Inspection No. 1310148th "state authority inspection - quality qualified product certificate" - - Certificate No. BHKU-S12456



First, product characteristics



(1) overview of product function:



This product is a broadband transmitter (without GSM, DCS, PCS, 4G upstream working frequency) from 870 to 880MHz, 930~960 MHz, 1805 to 1920MHz, 2010 to 2145MHz, 2400 to 2500MHz, 2300 to 2370MHZ, 2555 to 2655MHZ, and a wireless device for truncating the signal between the launching pad (base station) and the hand machine, which can shield 2.4 no Line signal.



This product can effectively shield the microwave signal between the launching pad (base station) and the mobile phone, so that the mobile phone that needs the shielding area (including GSM, CDMA, DCS, PHS, 3G, 4G) is connected to the outside world. The product is compact and easy to use. It can be applied to various environments with different areas through separate and distributed layout.



(two) technical performance indicators:



The following is the QP-Lj-4G type custom machine index



Output end



frequency



Average output power



Channel output power



CDMA



870-880MHz



35dBm



10dBm/100kHz



GSM



930-960MHz



35dBm



5dBm/100kHz



DCS/PHS



1805-1920MHz



33dBm



2dBm/100kHz



3G



2010-2145MHz



33dBm



2dBm/100kHz



4G



2300-2370MHz



33dBm



2dBm/100kHz



4G



2555-2655MHz



33dBm



2dBm/100kHz








Required power supply: alternating current converter (AC220V-DC4.2V) shielding radius: (2-50)



Safety regulation: UL (E190582) CSA (LR11291Level13) size (width * height * depth): 310 x 110 x 35mm



Power consumption: 50W weight: about 3Kg





Key technology solutions and important functions:





A. ultra high frequency wideband interference technology





The realization of the core function of the technology (single frequency band) consists of two functional IC and its peripheral matching circuit.





TXVCO (commonly known as interference source): VCO is a synthetic component, in fact a voltage - frequency conversion device, which converts the variation of the phase voltage signal output by the phase detector to the change of frequency, thus producing the desired interference source.





PA (power amplifier): the internal PA is composed of power drive, power amplification, detection and other parts, so the peripheral PA is added to match high frequency rectifier, power detection and error voltage amplification.









The key point of realizing the function of the TX-101E-6A mobile phone shielding device is to break through the following two aspects:



(1) broadband, high power output: to improve the broadband power gain, the power stability control after the increase of the gain, the intra band stability and the control of the band out of band, the control of the outshoot index, the wide frequency output Bobbi index (some indexes are repeatedly adjusted before the design of the R & D scheme, the normal production, the product quality. " After stability).



(2) interference between multiple systems: in the smaller space of the shielding machine, there are 6 systems launching, CDMA, GSM, DCS/PHS and 3G.4G.
